Overview

The Query API lets you use your own unique queries to fetch the particular pre-aggregated analytics data that you're interested in.

Benefits

The Branch Query API gives you access to the same pre-aggregated analytics data that is displayed in Branch, without needing to access the web app itself.

An individual query consists of three types of parameters:

• Authentication parameters that control access to the data.
• Data selection keys that define which events are eligible to be counted in the results (for example, filters).
• Result format specifiers that define which results are included in the HTTP response and how the results are returned (for example, sorting).

Limits

Limitation	Details
Rate limits	- 5 requests per second - 20 requests per minute - 150 requests per hour If you've hit the rate limit, you'll see an error message that says Limit is exceeded for org.... in the response body.
Max number of rows returned from API	50,000
Max retrievable unique values for a single dimension (for example, campaigns or ad names)	40,000
Max number of days that can be queried at a time	7 days If more records are required, make multiple requests with smaller time intervals to pull the necessary data in batches.
Export window	Rolling 2-year window.
Specific dimension combinations	If you're pulling from SAN cost, xx_click, or xx_impression data, you cannot use the following dimension combinations: 1. user_data_os together with user_data_geo_country_code 2. last_attributed_touch_data_tilde_secondary_publisher together with user_data_geo_country_code

Getting started

Before you begin

To use the Query API, you first need to:

1. Create a Branch account.
2. Enable Universal Ads and start running ad campaigns from your Branch account.
3. Implement the appropriate Branch SDK into your mobile app (iOS | Android).
4. Make sure you have the appropriate permissions set on your user account. See the Access section for more.

Access

General access

To access the Query API, a user must have both Aggregate Data and Export access enabled on their account.

Agency access

If you work with an agency that runs your advertising campaigns and want to give them access to export the subsequent data, you can provide them with access to the Export API.

To provide an agency team member with access to the Export API:

1. In the left-hand navigation, under Setup & Testing, select Account Settings.

2. On the Account Settings page, select the Agencies tab.

3. Expand the agency in question, find the agency team member you want to give access to, hover over the button in the Actions column, and select Edit.

4. In the Edit Agency Team Member modal:

   1. Under Access Level, check the Export box.
   2. Under Permissions, check the Aggregate Data box.

5. Optional: Add data filters.

   1. Under Data Filters, toggle any necessary data filters on. Exported data will be filtered accordingly.

6. Select Save.

Agency-tagged data

If you do not enable the "Only Show Agency-Tagged Data" filter, the agency team member can export aggregate data associated with all of your campaigns, regardless of whether they are associated with them or not.

Authentication

For calls to the Query API, you need your Branch Key and Branch Secret.

Legacy Branch

To retrieve your credentials in the legacy Branch experience:

1. Navigate to the Account → Settings → Profile tab.
2. Use the copy icons to copy your Branch Key and Branch Secret.

New Branch

To retrieve your credentials in the new Branch experience:

1. Navigate to the Configuration → Security & Access → Credentials tab.
2. Use the copy icons to copy your Branch Key and Branch Secret.

Visit our guide to learn more about managing your Branch credentials.

Usage

Post query

Request info

Export request

POST /v1/query/analytics
Content-Type: application/json
Host: api2.branch.io

Request headers

Header	Description	Required
accept	application/json	Yes
content-type	application/json	Yes

Request query parameters

Parameter	Type	Description	Required
branch_key	String	The Branch Key for the relevant application.	Yes
branch_secret	String	The Branch Secret for the relevant application, used for authentication.	Yes
limit	Integer	The maximum number of results to return in the response. Default value: 100 Max value: 1000 For example, if the granularity in the request body is set to day, Branch pulls results up to the limit for each day. So if the limit is set to 1000 and you query 5 days' worth of data, the API returns up to 5000 results.	No
after	Integer	A pagination parameter that indicates the index of the first result to return in the response. Default value: 0 For example, in a query with 100 results returned, setting after to 50 returns elements 51-100.	No
query_id	String	The value passed for this parameter is returned as a query parameter within the paging object. Default value: null This parameter locks the last event to include in a query, so new events that occur between queries are not added to the results. This prevents counts from changing over time. Note: The query_id parameter should be treated as temporary and should only be used when retrieving pages of an existing query where the pagination URLs already have query_id set as a parameter. Do not attempt to change the query_id between requests or to include a query_id with a different query request.	No

Request body parameters

Parameter	Type	Description	Required
start_date	Date	A timestamp representing the oldest date to return data for. The time zone of the timestamp is set in your Branch configuration. The format is an ISO-8601 compliant date-time string, for example, "2024-01-20"	Yes
end_date	Date	A timestamp representing the most recent date to return data for. The time zone of the timestamp is set in your Branch configuration. No events triggered after end_date will be counted in the query results. The end_date parameter cannot be more than 7 days after the start_date parameter. The format is an ISO-8601 compliant date-time string, for example, "2024-01-20"	Yes
data_source	String	The type of event to query for, prefixed with the source. For example, the source eo and the open event type come together to make eo_open, which pulls Branch app opens. Valid Branch data source values: eo_impression eo_click xx_impression xx_click eo_branch_cta_view eo_sms_sent eo_open eo_install eo_reinstall eo_web_session_start eo_pageview eo_commerce_event eo_custom_event eo_content_event eo_dismissal eo_user_lifecycle_event cost	Yes
aggregation	String	How to count events toward the final result count. Possible aggregation values: unique_count total_count revenue cost cost_in_local_currency Note: When using unique_count, each event is only counted if an event triggered by that user has not already been seen. For example, if 10 users each trigger 3 opens, only 10 open events will be counted.	Yes
dimensions	Array of Strings	List of event fields to use as splits for the query. Result counts are returned and grouped with other events that have matching values for each key provided in dimensions. See the Dimensions section for a complete list.	Yes
filters	Array of Strings	An object where each key is a valid dimension, and each value is an array of string values to check against. If a key is prefixed with a !, then any event with that dimension value will be excluded. Otherwise, only events with dimension values matching the filter will be counted. See the Example Queries section for examples of the filters array. Also see the Dimensions section for a complete list of valid key values. Any key may be used with the ! prefix.	No
enable_install_recalculation	Boolean	Dedupe unattributed installs caused by duplicate events from non-opt-in users coming from paid ads. This parameter is related to iOS 14.5 privacy changes.	No
granularity	String	Range of time to roll multiple events into a single result count. For example, with a granularity value of day, the counts for each day are returned independently, whereas all returns a single count for the entire time range. Possible values: all day Default value: all Note: When you set all for this key, Branch returns the data grouped by start_date. The start_date shown is for the start of the range, and does not mean that data is limited to just that day.	No
ordered_by	String	The result key to sort results by. Only 1 sort key is supported. Possible values include any dimensions value or the value of aggregation. Possible numerical sorting values: - unique_count - total_count - revenue Possible chronological sorting values: - timestamp Possible lexicographical sorting values: - All others Note: It's not possible to provide an explicit sort method to the query, so the sort type is chosen automatically based on the value of this ordered_by parameter. Behavior for comparison of equal values is left undefined, and as such, the sort is not considered order stable for identical values.	No
ordered	String	The direction by which to order the results. Possible values: ascending descending Default value: descending	No
zero_fill	Boolean	Whether to return result objects where the result count is 0. If set to false, empty results are omitted from the response. If true, fields for empty results are loaded with null or 0 to provide a schema. See the Example Queries section for an example of how this flag works.	No

Response info

Response body parameters

Parameter	Type	Description
results	List of Objects	A list of JSON objects that contain result information.
result	Object	A JSON object containing the queried values, for example, attributed or total_count. Nested inside results, alongside timestamp.
timestamp	Date	The date and time when the data related to the result was created. Nested inside results, alongside result.
paging	Object	A JSON object that includes the total number of results from the query, called total_count. This object also includes the number that the results are limited to, if that was included in the request. See limit and after in the Request Query Parameters section for further information.

Example request & response

Total installs

Below is an example of a basic query that pulls the total number of installs per day, split by whether attributed is true or false. The number of results is limited to 5.

Request (cURL)

curl -X POST -H "Content-Type: application/json" -d '{
    "branch_key":"<YOUR_BRANCH_KEY>",
    "branch_secret":"<YOUR_BRANCH_SECRET>",
    "start_date": "2022-03-01",
    "end_date": "2022-03-07",
    "data_source": "eo_install",
    "dimensions": [
        "attributed"
    ],
    "enable_install_recalculation": true,
    "granularity": "day",
    "aggregation": "total_count"
}' "https://api2.branch.io/v1/query/analytics?limit=5"

Response (JSON)

{
  "results": [{
      "result": {
        "attributed": "false",
        "total_count": 44
      },
      "timestamp": "2022-03-05T00:00:00.000Z"
    }, {
      "result": {
        "attributed": "false",
        "total_count": 23
      },
      "timestamp": "2022-03-07T00:00:00.000Z"
    }, {
      "result": {
        "attributed": "true",
        "total_count": 14
      },
      "timestamp": "2022-03-05T00:00:00.000Z"
    }, {
      "result": {
        "attributed": "false",
        "total_count": 12
      },
      "timestamp": "2022-03-03T00:00:00.000Z"
    }, {
      "result": {
        "attributed": "false",
        "total_count": 10
      },
      "timestamp": "2022-03-02T00:00:00.000Z"
  }],
  "paging": {
    "next_url": "/v1/query/analytics?limit=5&after=5",
    "total_count": 13
  }
}

See Example Queries for more examples.

Appendix

Dimensions

General information

Dimension	Description
name	Name.
origin	Origin of the data.
timestamp	Timestamp of the data.
deep_linked	Is the data deep linked? Can be true or false.
from_desktop	Is the data from desktop? Can be true or false.
attributed	Is the data attributed? Can be true or false.

User information

Dimension	Description
user_data_app_store	User's app store. Not applicable to the following data source options: eo_impression, eo_click, xx_impression, xx_click, eo_branch_cta_view, eo_sms_sent, eo_web_session_start, eo_pageview, eo_dismissal, cost
user_data_app_version	User's version of the app.
user_data_os	User's operating system.
user_data_language	User's language.
user_data_platform	User's platform.
"user_data_environment"	User's environment.
user_data_geo_dma_code	User's geographical Designated Market Area code.
user_data_geo_country_code	User's country code.
user_data_country	User's country.
user_data_geo_region_en	User's region.
user_data_opted_in	Is the user opted in?
user_data_opted_in_status	User's opt-in status.

Custom event information

Dimension	Description
event_data_custom_param_1 event_data_custom_param_2 event_data_custom_param_3	Available dimensions for custom event data. Not applicable to the following data source options: eo_impression, eo_click, xx_impression, xx_click, eo_branch_cta_view, eo_sms_sent, eo_pageview, eo_dismissal, cost

Click & impression source definitions

Data source	Description
eo_impression	Real-time user device-level impressions and ad views triggered via Impression Tracking Ad Links. SAN ad partners' impressions are not included in this data source.
eo_click	Real-time user device-level Branch Link clicks. SAN ad partners' clicks are not included in this bucket.
xx_impression	Combined aggregated data source containing both real-time user device-level impressions and SAN ad partner impressions passed to Branch from SAN servers.
xx_click"	Combined aggregated data source containing both real-time user device-level Branch Link clicks and SAN ad partners' clicks passed to Branch from SAN servers.

SAN ad partners list:

• Facebook
• Google Ads
• X (formerly Twitter)
• Snap
• Apple Search Ads
• TikTok

Example queries

Installs per day per OS

This query pulls installs per day and splits the results by OS of the device the user installed on. It limits the number of results to 5.

Request (cURL)

curl -X POST -H "Content-Type: application/json" -d '{
    "branch_key":"<YOUR_BRANCH_KEY>",
    "branch_secret":"<YOUR_BRANCH_SECRET>",
    "start_date": "2017-12-12",
    "end_date": "2017-12-18",
    "data_source": "eo_install",
    "dimensions": [
        "user_data_os"
    ],
    "enable_install_recalculation": true,
    "granularity": "day",
    "aggregation": "total_count"
}' "https://api2.branch.io/v1/query/analytics?limit=5"

Response (JSON)

{
  "results": [
    {
      "result": {
        "user_data_os": "ANDROID",
        "total_count": 144
      },
      "timestamp": "2017-12-18T00:00:00.000Z"
    },
    {
      "result": {
        "user_data_os": "IOS",
        "total_count": 142
      },
      "timestamp": "2017-12-18T00:00:00.000Z"
    },
    {
      "result": {
        "user_data_os": "IOS",
        "total_count": 191
      },
      "timestamp": "2017-12-17T00:00:00.000Z"
    },
    {
      "result": {
        "user_data_os": "ANDROID",
        "total_count": 194
      },
      "timestamp": "2017-12-17T00:00:00.000Z"
    },
    {
      "result": {
        "user_data_os": "ANDROID",
        "total_count": 246
      },
      "timestamp": "2017-12-16T00:00:00.000Z"
    }
  ],
  "paging": {
    "next_url": "/v1/query/analytics?query_id=CqdBOb&limit=5&after=5",
    "total_count": 14
  }
}

Unique click counts

Below is a more complex query for pulling unique click counts. These counts are split out by 4 different dimensions.

This query also has a filter, which filters out any clicks where last_attributed_touch_data_plus_current_feature was MOBILE_DEEPVIEWS or DESKTOP_DEEPVIEWS.

A maximum of 5 results are returned, in descending order of unique_count. Results with days that had 0 clicks are returned (and not filtered out) because the zero_fill flag is set to true:

Request (cURL)

curl -X POST -H "Content-Type: application/json" -d '{
    "branch_key":"<YOUR_BRANCH_KEY>",
    "branch_secret":"<YOUR_BRANCH_SECRET>",
    "start_date": "2017-12-12",
    "end_date": "2017-12-18",
    "data_source": "eo_click",
    "dimensions": [
        "last_attributed_touch_data_tilde_feature",
        "last_attributed_touch_data_tilde_channel",
        "last_attributed_touch_data_tilde_campaign",
        "last_attributed_touch_data_plus_current_feature"
    ],
    "filters": {
        "!last_attributed_touch_data_plus_current_feature": [
            "MOBILE_DEEPVIEWS",
            "DESKTOP_DEEPVIEWS"
        ]
    },
    "ordered": "descending",
    "ordered_by": "unique_count",
    "aggregation": "unique_count",
    "zero_fill": true
}' "https://api2.branch.io/v1/query/analytics?limit=5"

Response (JSON)

{
  "results": [
    {
      "timestamp": "2017-12-12T00:00:00.000Z",
      "result": {
        "last_attributed_touch_data_tilde_channel": "ads",
        "last_attributed_touch_data_tilde_campaign": "Xmas",
        "last_attributed_touch_data_tilde_feature": "paid advertising",
        "last_attributed_touch_data_plus_current_feature": "ADS",
        "unique_count": 750
      }
    },
    {
      "timestamp": "2017-12-12T00:00:00.000Z",
      "result": {
        "last_attributed_touch_data_tilde_channel": "taptica#1",
        "last_attributed_touch_data_tilde_campaign": "taptica#1",
        "last_attributed_touch_data_tilde_feature": "paid advertising",
        "last_attributed_touch_data_plus_current_feature": "ADS",
        "unique_count": 723
      }
    },
    {
      "timestamp": "2017-12-12T00:00:00.000Z",
      "result": {
        "last_attributed_touch_data_tilde_channel": "Journeys",
        "last_attributed_touch_data_tilde_campaign": "Default Banner",
        "last_attributed_touch_data_tilde_feature": "journeys",
        "last_attributed_touch_data_plus_current_feature": "MOBILE_JOURNEYS",
        "unique_count": 553
      }
    },
    {
      "timestamp": "2017-12-12T00:00:00.000Z",
      "result": {
        "last_attributed_touch_data_tilde_channel": "Apple App Store",
        "last_attributed_touch_data_tilde_campaign": null,
        "last_attributed_touch_data_tilde_feature": "paid advertising",
        "last_attributed_touch_data_plus_current_feature": "ADS",
        "unique_count": 432
      }
    },
    {
      "timestamp": "2017-12-12T00:00:00.000Z",
      "result": {
        "last_attributed_touch_data_tilde_channel": null,
        "last_attributed_touch_data_tilde_campaign": null,
        "last_attributed_touch_data_tilde_feature": "marketing",
        "last_attributed_touch_data_plus_current_feature": "QUICK_LINKS",
        "unique_count": 201
      }
    }
  ],
  "paging": {
    "next_url": "/v1/query/analytics?query_id=EDdBOb&limit=5&after=5",
    "total_count": 143
  }
}

Include or omit response objects

When zero_fill is set to true, response objects with a total_count equal to 0 are returned alongside other results:

Request (JSON)

{
  "branch_key":"<YOUR BRANCH KEY>",
  "branch_secret":"<YOUR BRANCH SECRET>",
  "start_date": "2022-02-01",
  "end_date": "2022-02-01",
  "data_source": "xx_click",
  "dimensions": [
    "last_attributed_touch_data_tilde_advertising_partner_name",
    "last_attributed_touch_data_tilde_campaign_id"
  ],
  "ordered": "descending",
  "aggregation": "total_count",
  "zero_fill": true
}

Response (JSON)

{
  "result": {
    "last_attributed_touch_data_tilde_advertising_partner_name": "Google AdWords",
    "last_attributed_touch_data_tilde_campaign_id": "78726498102",
    "total_count": 1
  },
  "timestamp": "2022-02-01T00:00:00.000+08:00"
},
{
  "result": {
    "last_attributed_touch_data_tilde_advertising_partner_name": "Google AdWords",
    "last_attributed_touch_data_tilde_campaign_id": "87192837612",
    "total_count": 1
  },
  "timestamp": "2022-02-01T00:00:00.000+08:00"
}
{
  "result": {
    "last_attributed_touch_data_tilde_advertising_partner_name": "Google AdWords",
    "last_attributed_touch_data_tilde_campaign_id": "17384628491",
    "total_count": 0
  },
  "timestamp": "2022-02-01T00:00:00.000+08:00"
}

When zero_fill is set to false, response objects with a total_count equal to 0 are omitted:

Request (JSON)

{
  "branch_key":"<YOUR BRANCH KEY>",
  "branch_secret":"<YOUR BRANCH SECRET>",
  "start_date": "2022-02-01",
  "end_date": "2022-02-01",
  "data_source": "xx_click",
  "dimensions": [
    "last_attributed_touch_data_tilde_advertising_partner_name",
    "last_attributed_touch_data_tilde_campaign_id"
  ],
  "ordered": "descending",
  "aggregation": "total_count",
  "zero_fill": false
}

Response (JSON)

{
  "result": {
    "last_attributed_touch_data_tilde_advertising_partner_name": "Google AdWords",
    "last_attributed_touch_data_tilde_campaign_id": "78726498102",
    "total_count": 1
  },
  "timestamp": "2022-02-01T00:00:00.000+08:00"
},
{
  "result": {
    "last_attributed_touch_data_tilde_advertising_partner_name": "Google AdWords",
    "last_attributed_touch_data_tilde_campaign_id": "87192837612",
    "total_count": 1
  },
  "timestamp": "2022-02-01T00:00:00.000+08:00"
}
